Producto:

DP 505 White

Case Specification

Dimensions    481 x 220 x 490mm (DWH)

Form Factor    Mid Tower

Materials    Steel + Plastic

Mainboard Support    E-ATX, ATX, Micro-ATX, ITX

Front Access & Controls    Power, LED control button, USB 3.0 x 2, TYPE-C 3.2 Gen 2 x 1, MIC x 1, HD-AUDIO x 1

Side Panel    4mm Tempered Glass

Drive Bays

Expansion Slots    7

3.5" /2.5"    2 / 2

2.5"    2

Fan

Front    120mm x 3 / 140mm x 3 / 185mm x 2

Top    120mm x 3 / 140mm x 2

Power Supply Shroud    120mm x 2

Rear    120mm x 1

Included Fan(s)    120mm ARGB fans in front x 3

Radiator Support

Front    120 / 140 / 240 / 280 / 360mm

Top    120 / 140 / 240 / 280 / 360mm

Rear    120mm

Clearance

Max GPU Length    ≤ 375mm

Max CPU Cooler Height    ≤ 170mm

Max PSU Length    ≤ 205mm(with HDD)

≤ 410mm(without HDD)

Cable Routing Space    ≤ 23mm

Accessories

Fan & LED Control Hub    Yes

GPU Holder    Yes

Cable Routing Grommets    Yes, 8 pcs

Fixed Cable Ties    Yes, 3 pcs

Captive Thumb Screws    Yes (Side panels, GPU Holder, PSU Brace)

Miscellaneous

Dust Filter    Top / Bottom

Dust Filter    Top / Bottom

Net Weight    8.1 kgs

Gross Weight    9.1 kgs
