750W MWE BRONZE V3
MPE-7501-ACAAW-3B
Model MPE-7501-ACAAW-3B
ATX Version ATX 12V Ver. 3.1
PFC Active PFC
Input Voltage 100-240V
Input Current 10-6A
Input Frequency 50-60Hz
Dimensions (L x W x H) 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
Fan Size 120mm
Fan Bearing HDB
Efficiency >85% @ Typical Load
80 PLUS Rating 80 PLUS Bronze
ErP 2014 Lot 3 Yes
Operating Temperature 0-40°C
Power Good Signal 100 - 150 ms
Hold Up Time >16ms
MTBF >100,000 Hours
Protections UVP, OVP, OPP, OTP, SCP
Regulatory cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 2
SATA Connectors 6
Peripheral 4 Pin Connectors 3
PCI-e 6+2 Pin Connectors 4
Warranty 5 Years
Series MWE Bronze Series
80 Plus Bronze
Modular Non Modular
Category 500 to 750W
