FAN Specifications | FN12A-C8I |
Dimensions: | 120 x 120 x 25mm |
Fan Frame Colour: | Black |
Fan Blades / Colour: | 9 / semi-transparent white |
LED Qty / Type: | Center 8PCS,Outer ring 16PCS |
Bearing Type: | Hydraulic Bearing |
Fan Speed: | 800~1600 rpm ± 10% |
Max. Air Flow : | 44.35 CFM ± 10% |
Max. Static Air Pressure: | 1.42mm - H2O |
Noise Level (max.): | 31.21db(A) |
Cable Length : | 4pin(M/F) PWM Power / 3pin Aura(M/F), 500/500mm |
Accessories: | Screws |
Connectors: | 3pin AURA (M/F) & 4pin PWM Power(M/F) |
Rated Voltage: | 12V |
Rated Current (max.): | 0.15A (Max. 0.18A) |
Rated Input Power: | 1.8W (Max. 2.16W) |
Test Voltage : | 12V |
Start Voltage: | 5V |
M.T.B.F.: | 30,000 hrs |
