Form Factor (Midi, Micro, Mini ITX, Full) | Midi Tower | |
Chassis | SPCC: 0.4mm | |
Chassis | Black version | |
PSU Form Factor | Bottom/ATX | |
M/B Form Factor | EATX(280mm Max.),ATX,M-ATX,ITX | |
Front Panel | ABS | |
Top Panel | Metal cover | |
Side Panel | Left | Tempered Glass |
Right | Metal cover | |
External Drive Bay(s) | 5.25"(ODD) | *0 |
3.5" | *0 | |
Internal Drive Bay(s) |
3.5"(HDD) 2.5"(SSD) |
1*3.5HDD+5*2.5SSD or 2*3.5HDD+3*2.5SSD or 3*3.5HDD+2*2.5SSD |
I/O | Buttons | *2 |
USB3.0 Port(s),USB2.0 Port | *1x USB 3.0+1x USB 2.0 | |
HD Audio Support | Combo Audio(CTIA)*1 | |
Type c | *1(2.0 or GEN1 or GEN2) | |
P-Lock | *1 (optional) | |
Controller max. fans | *0 | |
RGB Controller max. LED strips | *0 | |
Cooling Fan Support | Front | 3x120mm(Fan Included) ,2x140mm(Fan optional) |
Top | 2x120mm(Fan Included) ,2x140mm(Fan optional) | |
Rear | 1x120mm (Fan Included) | |
PSU Cover | 2x120mm (Fan optional) | |
Water Cooling Support | Front | 120mm, 140mm,240mm,280mm.360mm |
Top | *0 | |
Rear | 120mm*1 | |
Dust Cover | Bottom and top cover with dust filter | |
Slots | *7 | |
Carton Logo | GAMEMAX | |
Dimensions | Chassis | (L)340*(W)200*(H)436mm |
Full Case (inc Fascia) | (L)386*(W)205*(H)449mm | |
Carton | (L)*(W)*(H)mm | |
Net Weight (Kg) | kgs | |
Gross Weight (Kg) | kgs | |
VGA Card Length | up to 330mm | |
CPU Cooler Height | 155mm | |
Cable Management Depth | 19mm |
