Producto: QUEST MESH

Model Quest SPECIFICATION
Form Factor (Midi, Micro, Mini ITX, Full) TOWER
Chassis SPCC :0.6mm
PSU Form Factor Bottom/ATX
M/B Form Factor E-ATX、ATX、M-ATX、ITX
Front Panel Metal cover
Top Panel Metal cover
Side Panel Left Tempered Glass
Right metal cover
Internal Drive
Bay(s) 3.5" (HDD) *2
2.5" (SSD) *3
1*3.5HDD+3*2.5SSD or 2*3.5HDD+2*2.5SSD
I/O Buttons *2
USB2.0 Port(s) *1
USB3.1 Port(s) *1
USB3.2 Port(s) *1 Type-C Gen2 (Type-E Connector)
Audio Support *1 (COMBO AUDIO)
RGB Controller *0
Cooling Fan
Support Front 3x120mm,3x140mm(Fan optional)
Top 3x120mm ,2x140mm (Fan optional)
Rear 1x120mm (Black Fan Incl.)
M/B Cover 2x120mm (Fan optional)
PSU Cover 2x120mm (Fan optional)
Water Cooling Support
(Radiator Size) Front 120mm, 140mm,240mm,280mm,360mm
Top 120mm, 140mm,240mm,280mm,360mm
Rear 120mm
M/B Cover 120mm, 240mm
Dust Cover Bottom, right side panel and top cover with dust filter
Slots *7
Carton Logo GAMEMAX
Dimensions Chassis (L)415*(W)210*(H)470mm
Full Case (inc Fascia) (L)463*(W)210*(H)485mm
VGA Card Length Up to 410mm(front cover w/o fan)
CPU Cooler Height 165mm
SPS Length Up to 265mm(front cover w/o Water Cooling)
Cable Management Depth 25mm
