BLADE CONCEPT
100280050144

Form Factor
- ATX

Chassis
- SPCC: 1.0-3.0mm

PSU Form Factor
- ATX

M/B Form Factor
- ATX

Front Panel
- N/A

Top Panel
- N/A

Side Panel
- Left: Metal
- Right: Metal

External Drive Bay(s)
- 5.25”(ODD): *0
- 3.5”: *0

Internal Drive Bay(s)
- 3.5" (HDD): *2
- 2.5" (SSD): *2

I/O
- Buttons: *1
- USB 2.0 Port(s): *0
- USB 3.0 Port(s): *2
- Type C Port(s): *1 (Gen2)
- Audio Support: *1
- Card Reader (Support): *0
- P-Lock: *0
- RGB Controller: *1 (GMX V4.0 ARGB/PWM HUB)
- Controller Max Fans: *9
- RGB Controller max. LED strips: *9
- Remote (IR or RF): *1

Cooling Fan Support
- Front: *0
- Top: *0
- Rear: *0
- Bottom: *0
- M/B Cover: *0
- PSU Cover: *0

Water Cooling Support (Radiator Size)
- Front: *0
- Top: *0
- Rear: *0
- M/B Cover: *360MM (M/B back)

Dust Cover
- N/A

Slots
- *3 (Vertical - mounted graphics card)

Carton & Logo
- GAMEMAX

Dimensions
- Chassis: (L)498*(W)254*(H)463mm
- Full Case (Inc Fascia): (L)498*(W)254*(H)470mm
- Carton: (L)610*(W)365*(H)575mm

Weight
- Net Weight(kg): 12.5
- Gross Weight(kg): 14.2

Clearance
- VGA Support: 400mm
- CPU Cooler Height: 105mm
- SPS Length: 230MM
