Materials - Exterior Steel
Material - Side Panel (Right) Steel
Material - Side Panel (Left) TG
Dimensions (L x W x H) Incl. Protrusions: 438.5 x 225 x 492.1 mm
Dimensions (L x W x H) Excl. Protrusions: 425 x 225 x 425 mm
Volume (w/o protrusions) 40.64 L
Volume (with panel, protrusions and feet) 48.55 L
Motherboard Support ITX / M-ATX / ATX / *E-ATX (*Up to 280 mm)
Expansion Slots 7
Drive Bays
- 3.5" HDD
1 (Shared 3.5" and 2.5" mounting on PSU bracket)
Drive Bays
- 2.5" SSD
2 (Max. 5)
I/O Panel - USB Ports 2 x USB 3.2 Gen 1 Type A / 1 x USB 3.2 Gen 2 x 2 Type C
I/O Panel - Audio In / Out 1 x 3.5 Mic / Audio Combo Jack
Fan Support - Front 3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Fan Support - Top 3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Fan Support - Rear 1x 120mm
Fan Support - Bottom 3 x 120 mm / 2 x 140 mm
Pre-installed Fans - Rear 1x 120mm Black Fan
Radiator Support - Front 140 / 280 / 360 mm (w/o I/O panel)
Radiator Support - Top 140 / 280 / 360 mm (w/o I/O panel)
Radiator Support - Rear 120 mm
Radiator Support - Bottom 140 / 280 / 360mm (w/o I/O panel)
Clearances - CPU Cooler 172 mm
Clearances - Power Supply 200 mm
Clearances - Graphics Card 415 mm (w/o Front Fan)
Cable Routing - Behind Motherboard Tray 27 mm
Dust Filters Top / Bottom / Front
Power Supply Support ATX / SFX
Warranty 2 years
Series QUBE Series
Size Mid Tower
