En Stock SKU: SKU

700W VP P PLUS EC


Product Name    VP700P PLUS

Model Name    V3000A104-18

Modular    Non-Modular

Dimension (W x L x H)    140(D)*150(W)*86(H)

Input Voltage    200-240 VAC ±10%

Input Current    5A

Input Frequency Range    47Hz-63Hz

PFC    Active PFC (>0.9 typical)

Power Good Signal    100-500ms

Efficiency    85% Typically

Protection    UVP/OVP/SCP/OPP/NLO

Output Capacity    700W

Regulatory    TUV/CB/CE

Fan    120mm Silent Fan

Certifications    80 Plus

Connector

-1 x MB 24(20+4) Pin

-1 x 8(4+4) Pin EPS 12V

-4 x 8(6+2) Pin PCI-E

-7 x SATA

-2 x Molex

-1 x FDD

Net Weight    1.89 Kgs

Gross Weight    2.31 Kgs
